Item |
PartNo |
Description |
Qty |
Options |
Ref |
Alt |
|
? |
58E-54-10111 |
INNER PANEL ASSEMBLY, RH (SEE INDEX) |
1 |
|
63304 |
|
|
? |
SM0926 |
CAPSCREW - M6 X 1.00 |
3 |
|
|
|
|
? |
58E-09-00080 |
CAPSCREW - M6 X 1.00 X 12 |
12 |
|
|
|
|
? |
SM2548 |
SEAL, DOOR |
1 |
|
|
|
|
? |
XB6192 |
FRAME, DOOR - RH |
1 |
|
|
|
|
? |
SM2544 |
HINGE, DOOR |
1 |
|
|
|
|
? |
58E-09-00090 |
CAPSCREW - M8 X 1.25 X 12 |
20 |
|
|
|
|
? |
EL5788 |
CHANNEL, WINDOW LIFT |
1 |
|
|
|
|
? |
31006R1 |
MACHINE SCREW - M6 X 1.00 X 16 |
4 |
|
|
|
|
? |
SM2832 |
BRACKET, WINDOW LIFT |
1 |
|
|
|
|
? |
SM2261 |
GASKET |
2 |
|
|
|
|
? |
MM0462 |
FLAT WASHER - M12 |
2 |
|
|
|
|
? |
EM7654 |
BUSHING, NYLON |
4 |
|
|
|
|
? |
EL5721 |
BRACKET, OUTER |
1 |
|
|
|
|
? |
SM2274 |
LATCH DOOR ASSEMBLY - RH |
1 |
|
|
|
|
? |
SM2263 |
LEVER, DOOR LATCH |
1 |
|
|
|
|
? |
TC1234 |
CAPSCREW - 3/8" - 16NC X 3/4" |
1 |
|
|
|
|
? |
TG9225 |
LOCKNUT - 3/8" - 16NC |
1 |
|
|
|
|
? |
SM2264 |
KNOB, DOOR LATCH |
2 |
|
|
|
|
? |
SM2354 |
SCREW - #10 - 24NC |
1 |
|
|
|
|
? |
SM2355 |
LOCKNUT - #10 - 24NC |
1 |
|
|
|
|
? |
KD0252 |
MACHINE SCREW - 1/4" - 20NC X 3/4" |
4 |
|
|
|
|
? |
SD4235 |
LOCKWASHER, EXTERNAL TOOTH - 1/4" |
4 |
|
|
|
|
? |
PC1828 |
HANDLE, PUSH BUTTON |
1 |
|
|
|
|
? |
MM0176 |
NUT - M6 X 1.00 |
1 |
|
|
|
|
? |
MM0584 |
CAPSCREW - M6 X 1.00 X 30 (STRIKER) |
1 |
|
|
|
|
? |
XB0815 |
PLATE |
1 |
|
|
|
|
? |
WB3550 |
SCREW, MACHINE - M6 X 20 |
3 |
|
|
|
|
? |
SM2406 |
SCREW, SELF-TAPPING - #6 - 32NC X 3/8" |
24 |
|
|
|
|
? |
SM2405 |
SEAL, WINDOW (INSIDE) |
1 |
|
|
|
|
? |
2048889R1 |
TRIM, BULK |
|
|
|
|
|
? |
58E-54-10100 |
WINDOW ASSEMBLY |
1 |
|
|
|
|
? |
58E-98-10530 |
• FILLER |
1 |
|
|
|
|
? |
58E-98-10500 |
• CHANNEL, GLASS |
1 |
|
|
|
|
? |
EL2724 |
• GLASS |
1 |
|
|
|
|
? |
58E-98-10510 |
• COVER, SCREW |
1 |
|
|
|
|
? |
58E-98-10520 |
• WIPE, GLASS |
1 |
|
|
|
