Item |
PartNo |
Description |
Qty |
Options |
Ref |
Alt |
|
? |
VE3530 |
INTERLOCK, POSITION SENSOR |
1 |
|
|
|
|
? |
XA4230 |
• BOX |
1 |
|
|
|
|
? |
BF3174 |
• COVER |
1 |
|
|
|
|
? |
VE1142 |
• PIN |
3 |
|
|
|
|
? |
VE3616 |
• INNER ARM ASSEMBLY |
1 |
|
|
|
|
? |
VE0735 |
• SPRING |
1 |
|
|
|
|
? |
VE5751 |
• MACHINE SCREW - #4 - 40NC X 5/8" |
1 |
|
|
|
|
? |
VE4908 |
• LOCKWASHER - #4 |
1 |
|
|
|
|
? |
VE4909 |
• NUT - #4 - 40NC |
1 |
|
|
|
|
? |
VE1143 |
• SPRING |
1 |
|
|
|
|
? |
VE4405 |
• STUD ASSEMBLY |
1 |
|
|
|
|
? |
VE4406 |
• STUD ASSEMBLY |
1 |
|
|
|
|
? |
VE5752 |
• STUD, TAPPED |
1 |
|
|
|
|
? |
VE5753 |
• MACHINE SCREW - #4 - 40NC X 1/4" |
1 |
|
|
|
|
? |
SF2755 |
• NUT - #10 - 32NF |
3 |
|
|
|
|
? |
VE4907 |
• FLAT WASHER - #4 |
1 |
|
|
|
|
? |
BF0020 |
• MACHINE SCREW - #6 - 32NC X 5/8" |
5 |
|
|
|
|
? |
VC1390 |
• LOCKWASHER - 5/8" |
5 |
|
|
|
|
? |
HE5125 |
• FLAT WASHER - #6 |
5 |
|
|
|
|
? |
VE5757 |
• OUTER ARM ASSEMBLY |
1 |
|
|
|
|
? |
TR5445 |
• LOCKWASHER - 1/2" |
3 |
|
|
|
|
? |
VS6662 |
• FLAT WASHER - #10 |
3 |
|
|
|
