Item	PartNo	Description	Qty
?	VS8925	MAGNET, FRAME	1
?	VS8908	CORE	1
?	GE0349	FRAME, SPRING BRACKET	1
?	VJ9134	CAPSCREW / LOCKWASHER - 3/8" - 16NC X 3/4"	2
?	VE5759	SPRING W/PLUG	1
?	VE5771	LOCKWASHER, EXTERNAL TOOTH - #10	1
?	SF2755	NUT - #10 - 32NF	1
?	BF1890	ARMATURE ASSEMBLY	1
?	VS9034	MACHINE SCREW - #10 - 32NF X 2 7/16"	1
?	VS9209	MACHINE SCREW / LOCKWASHER - #10 - 32NF X 1/2"	2
?	VS9172	PIN	1
?	VS6881	WASHER - 5/16" (BRASS)	2
?	VS9171	CLAMP	2
?	VJ2551	MACHINE SCREW / LOCKWASHER - 5/16" - 18NC X 1/2"	2
?	VS8285	CONTACT ARM	1
?	VE5761	COTTER PIN	1
?	VS9175	SEAT, SPRING	1
?	VM0253	SPRING	1
?	VM0275	SHUNT	1
?	DC3584	LOCKWASHER - 1/4"	3
?	VE4347	NUT - 1/4"	3
?	VM0217	HORN, ARC CHUTE	1
?	VM0229	HORN, ARCING	2
?	VJ7860	CAPSCREW - 5/16" - 18NC X 1 1/4"	4
?	VE4696	LOCKWASHER - 5/16"	8
?	TR1307	FLAT WASHER - 1/4" (NARROW)	8
?	VE1183	TIP, CONTACT	2
?	VE0252	WASHER, SPRING	1
?	XA4234	COIL, OPERATING	1
?	VS9212	CAPSCREW - 3/8" - 16NC X 1 1/4"	1
?	VE3288	PLATE, LOCKING	1
?	VS7830	SPACER	1
?	XA4232	CAPSCREW - 1/4" - 20NC X 3 3/4"	5
?	VS7132	INSULATION	1
?	VE5885	SUPPORT, BLOWOUT COIL	1
?	BF1893	SUPPORT	1
?	GE0648	CAPSCREW - 5/16" - 18NC X 2 1/4"	2
?	XA4231	CAPSCREW - 5/16" - 18NC X 2 1/8"	2
?	VE7202	WASHER - 1/4" (NARROW)	1
?	VJ8979	CLAMP	1
?	VE2248	SHIM	2
?	VJ0846	ARC CHUTE ASSEMBLY	1
?	VJ8966	• LH SIDE, ARC CHUTE	1
?	BF1894	• CAPSCREW - 1/4" - 20NC X 1 1/4"	1
?	XA4233	• FLAT WASHER - 1/4"	2
?	DC3584	• LOCKWASHER - 1/4"	6
?	TD1549	• NUT - 1/4" - 20NC	6
?	VE5778	• PIECE, POLE	1
?	BF1895	• CAPSCREW - 1/4" - 20NC X 3 1/4"	5
?	VS6696	• BUSHING	4
?	VJ8965	• RH SIDE, ARC CHUTE	1
?	VE7202	• WASHER - 1/4" (NARROW)	2
?	VS6695	• BUSHING	4
?	VS6697	• SUPPORT	2
?	VE1076	• PIECE, POLE	1
?	VJ8710	INSULATION FLANGE	2
?	BF0705	CAPSCREW - #10 - 32NC X 1/2"	2
?	BF1891	CORE FLANGE	2
?	BF1892	CORE	1
?	BF1896	INSULATION TUBE	1
