Корень Dump Trucks Komatsu AFE NEW AFE73-X 980E-4 S/N A40178 - A40180 BUENAVISTA(afe73-x)
COOLING SYSTEM PIPING 1/4(068 : 62896)
































Item PartNo Description Qty Options Ref Alt
? HA8277 HOSE 1
? TD9743 FITTING, STRAIGHT 1
? WA3038 FITTING, STRAIGHT 3
? 58B-03-00650 HOSE 1
? 58B-03-00660 HOSE 1
? C5770 PLUG, PIPE - 3/8" 2
? HA7598 HOSE 1
? 58F-94-00020 CLAMP, T-BOLT 4
? WB3094 CLAMP, CUSHIONED - 1 3/4" 9
? TC1233 NUT - 3/8" - 16NC 4
? TR4436 FLAT WASHER, HARDENED - 3/8" 4
? WB1142 FITTING, ADAPTER 3
? WB1300 CLAMP, CUSHIONED - 5/8" 2
? MM0604 CAPSCREW - M10 X 1.50 X 20 2
? MM0461 FLAT WASHER - M10 12
? MM0178 NUT - M10 X 1.50 12
? 58B-03-00670 BRACKET 1
? 426-06-11570 BRACKET 1
? MM0605 CAPSCREW - M10 X 1.50 X 25 2
? ED8256 TUBE 2
? PC0818 FITTING, ADAPTER 2
? TM2966 HOSE 1
? WB1303 CLAMP, CUSHIONED - 3/4" 5
? VY8331 CLAMP, VINYL - 1/4" 2
? XB9060 HOSE 1
? 58F-06-03140 BRACKET 1
? TR9082 FLAT WASHER - 5/8" 1
? KC1255 CLAMP 2
? WB3097 CLAMP, CUSHIONED - 1/2"
? TC1231 LOCKWASHER - 3/8" 3
? WA4726 FLAT WASHER, HARDENED - 3/8" 6
? XB8464 BRACKET 1
