Item	PartNo	Description	Qty
?	58B-03-00110	RADIATOR, AFTERCOOLER (LTC)	1
?	58B-03-00380	• MEMBER, SIDE	1
?	58B-03-00390	• MEMBER, SIDE	1
?	58B-03-00360	• TANK, CENTER	1
?	58B-03-00370	• TANK, TOP	1
?	58B-03-00350	• SHROUD, FAN	1
?	58B-03-00400	• TIE, TENSION	2
?	C1540	• LOCKWASHER - 1/2"	28
?	VE3460	• CAPSCREW, HEAVY DUTY - 1/2" - 13NC X 1"	28
?	XA2721	• SEAL, RUBBER (LOCKING)	836
?	XA2720	• SEAL, RUBBER	836
?	58B-03-00310	• TUBE	836
?	58B-03-00270	• BAR, SUPPORT	2
?	58B-03-00260	• BAR, SUPPORT	2
?	58B-03-00300	• AIR BAFFLE, BOTTOM	4
?	58B-03-00290	• AIR BAFFLE, TOP	4
?	C1602	• CAPSCREW - 3/8" - 16NC X 1"	16
?	58B-03-00320	• FLAT WASHER - 3/8"	16
?	58B-03-00330	• LOCKNUT - 3/8" - 16NC	16
?	58B-03-00340	• SCREW, FLAT HEAD - 3/8" - 16NC X 1"	8
?	58B-03-00100	RADIATOR, JACKET WATER (HTC)	1
?	58B-03-00220	• TANK, TOP	1
?	58B-03-00210	• TANK, CENTER	1
?	58B-03-00200	• TANK, BOTTOM	1
?	58B-03-00230	• MEMBER, SIDE	1
?	58B-03-00240	• MEMBER, SIDE	1
?	58B-03-00250	• TIE, TENSION	2
?	C1528	• NUT - 3/4" - 16NF	12
?	VE1285	• BRACKET, X-BRACE	2
?	XA2721	• SEAL, RUBBER (LOCKING)	840
?	XA2720	• SEAL, RUBBER	840
?	58B-03-00290	• AIR BAFFLE, TOP	4
?	58B-03-00300	• AIR BAFFLE, BOTTOM	4
?	C1540	• LOCKWASHER - 1/2"	20
?	VE3460	• CAPSCREW, HEAVY DUTY - 1/2" - 13NC X 1"	20
?	XA2806	• FLAT WASHER - 5/16"	6
?	C5747	• CAPSCREW - 5/16" - 18NC X 3/4"	4
?	VE6312	• NUT - 5/16" - 18NC	2
?	58B-03-00310	• TUBE	840
?	58B-03-00280	• ROD, X-BRACE	2
?	VE8559	• LOCKWASHER - 3/8"	8
?	C1602	• CAPSCREW - 3/8" - 16NC X 1"	24
?	58B-03-00270	• BAR, SUPPORT	2
?	58B-03-00260	• BAR, SUPPORT	2
?	58B-03-00320	• FLAT WASHER - 3/8"	16
?	58B-03-00330	• LOCKNUT - 3/8" - 16NC	16
?	58B-03-00340	• SCREW, FLAT HEAD - 3/8" - 16NC X 1"	8
