k-part

Item	PartNo	Description	Qty
?		AUTOMATIC FILL CONTROL (AFC) BOX (1)	1
?	C5746	CAPSCREW - 1/4" - 20NC X 3/4"	4
?	C1546	FLAT WASHER - 1/4"	8
?	C5780	NUT - 1/4" - 20NC	4
?	EK0195	PLATE, MOUNTING	1
?	MM0036	CAPSCREW - M10 X 1.50 X 20	2
?	MM0461	FLAT WASHER - M10	16
?	MM0471	LOCKWASHER - M10	2
?	MM0604	CAPSCREW - M10 X 1.50 X 20	2
?	MM0178	NUT - M10 X 1.50	7
?	EM3586	SPACER	1
?	WB3917	NUT, COUPLING	5
?	EK9883	SPACER	1
?	58B-06-20020	BRACKET	10
?	WB3096	CLAMP, CUSHIONED - 1 1/4"	1
?	WB1184	NUT, COUPLING	1
?	58B-06-10291	HARNESS, WIRING - ENGINE OIL RESERVE SYSTEM	1
?	WB3098	CLAMP, CUSHIONED - 3/8"	4
?	SD5211	BUSHING, PIPE	1
?	58F-06-10830	SWITCH, THERMOSTAT	1
?	MM0607	CAPSCREW - M10 X 1.50 X 35	2
?	MM0603	CAPSCREW - M10 X 1.50 X 16	4
?	EM1393	SPACER	2
?	WB3922	CLAMP, CUSHIONED - 11/16"	8
?	WB3097	CLAMP, CUSHIONED - 1/2"	9
?	58B-03-00670	BRACKET	1
?	MM0605	CAPSCREW - M10 X 1.50 X 25	1
?	58E-09-00000	PLATE	1
?	08193-21012	CLIP	2
?	58E-61-00221	NOTE: (1) INCLUDED IN 58E-61-00221 RESERVE SYSTEM KIT.
