Корень Dump Trucks Komatsu AFE NEW AFE73-X 980E-4 S/N A40178 - A40180 BUENAVISTA(afe73-x)
ACCESSORY DRIVE PIPING 1/2(592 : 62947)























Item PartNo Description Qty Options Ref Alt
? WB0542 FITTING, ELBOW - 45 DEG 1
? 58B-60-30000 HOSE 1
? MM0611 CAPSCREW - M10 X 1.50 X 60 2
? WB3855 CLAMP, CUSHIONED - 13/16" 13
? MM0461 FLAT WASHER - M10
? MM0471 LOCKWASHER - M10
? EL3892 SPACER 4
? 58B-60-02590 HOSE 1
? WB0821 FITTING, STRAIGHT 1
? WB1308 CLAMP, CUSHIONED - 1 1/16" 12
? 426-06-11570 BRACKET 2
? MM0610 CAPSCREW - M10 X 1.50 X 50 2
? MM0603 CAPSCREW - M10 X 1.50 X 16 8
? WB1163 NUT, COUPLING 8
? EM7532 SPACER 1
? WB3096 CLAMP, CUSHIONED - 1 1/4" 1
? MM0178 NUT - M10 X 1.50 2
? TY8375 SPACER 5
? MM0604 CAPSCREW - M10 X 1.50 X 20 2
? 58B-54-30070 BRACKET 1
? 58B-54-30040 BRACKET 1
? 58B-60-02450 HOSE 1
? WB3917 NUT, COUPLING 1
