k-part

Item	PartNo	Description	Qty
?	58F-04-00270	HOSE	1
?	WA0237	O-RING	2
?	TA1691	GASKET	1
?	VN6832	CAPSCREW - 1/4" - 20NC X 5"	6
?	58B-04-00770	FLANGE	1
?	TC1231	LOCKWASHER - 3/8"	6
?	TD0789	CAPSCREW - 3/8" - 16NC X 1 3/4"	6
?	58B-04-00760	RECEIVER	1
?	WA0237	O-RING	2
?	58B-04-10010	RECEIVER ASSEMBLY	1
?	58F-04-00751	FLANGE	1
?	VL9963	CLAMP, SPLIT FLANGE - 3"	4
?	C1541	LOCKWASHER - 5/8"	8
?	C1632	CAPSCREW - 5/8" - 11NC X 2 1/2"	8
?	WB0992	CLAMP	1
?	58B-80-02640	BRACKET	1
?	WB1055	CLAMP, VINYL - 3 1/2" ID	1
?	VW0967	CLAMP, VINYL - 3 9/16"	1
?	C1540	LOCKWASHER - 1/2"	4
?	TR1376	CAPSCREW - 1/2" - 13NC X 1 1/4"	4
?	58B-04-00531	BRACKET, FUEL RECEPTACLE	1
?	58B-04-10150	DOOR, FUEL	1
?	58B-04-10020	RECEPTACLE ASSEMBLY	1
?	VN6781	CAPSCREW, SOCKET HEAD - 1/4" - 20NC X 3"	6
?	C1607	CAPSCREW - 3/8" - 16NC X 5"	1
?	TR4436	FLAT WASHER, HARDENED - 3/8"	2
?	HE5611	LOCKNUT - 3/8" - 16NC	1
?	58B-04-00680	SPACER, TUBE	1
?	PC2271	GASKET	2
?	MM0606	CAPSCREW - M10 X 1.50 X 30	2
?	MM0471	LOCKWASHER - M10	2
?	MM0461	FLAT WASHER - M10	2
?	MM0619	CAPSCREW - M12 X 1.75 X 35	1
?	MM0462	FLAT WASHER - M12	2
?	MM0472	LOCKWASHER - M12	1
?	MM0179	NUT - M12 X 1.75	1
?	DC3584	LOCKWASHER - 1/4"	6
?	WA0154	O-RING	2
