k-part

Item	PartNo	Description	Qty
?	VC8762	CAPSCREW - 3/8" - 16NC X 1 1/2"	24
?	TR4436	FLAT WASHER, HARDENED - 3/8"	48
?	TC1233	NUT - 3/8" - 16NC	24
?	TC1231	LOCKWASHER - 3/8"	24
?	EK6385	BUS BAR	2
?	EK6384	BUS BAR	2
?	EK6383	BUS BAR	2
?	MM0461	FLAT WASHER - M10	4
?	MM0178	NUT - M10 X 1.50	4
?	WB3097	CLAMP, CUSHIONED - 1/2"	1
?	58B-06-20141	HARNESS, WIRING - REAR WHEEL SPEED	1
?	WA5642	MACHINE SCREW - #4 - 40NC X 1/2"	8
?	WB0904	PLATE, NUT CONNECTOR	2
?	TR4434	CAPSCREW - 3/8" - 16NC X 2"	12
?	MM0181	NUT - M16 X 2.00	8
?	EC1090	STUD, THREADED	8
?	XB1109	CLAMP, CABLE	8
?	MM0464	FLAT WASHER - M16	8
?	MM0474	LOCKWASHER - M16	8
?	MM0471	LOCKWASHER - M10	4
?	WB1300	CLAMP, CUSHIONED - 5/8"	1
?	58B-06-20240	HARNESS, WIRING - BLOWER PRESSURE SWITCH	1
?	WB1304	CLAMP, CUSHIONED - 9/16"	1
?	58F-06-03750	BLOWER PRESSURE SWITCH ASSEMBLY	1
?	58F-06-01860	• SWITCH, BLOWER PRESSURE	1
?	H8136	CAPSCREW - 1/4" - 20NC X 1/2"	4
?	C5774	LOCKWASHER - 1/4"	4
?	TK7603	TUBE, NYLON	1
?	WB0324	FITTING	1
?	VZ3370	VENT, BREATHER	1
?	TA0603	FITTING, NYLON	2
?	EL9925	HARNESS, WIRING - BLOWER PRESSURE SWITCH	1
?	58B-06-20020	BRACKET	1
?	58B-06-10940	PLATE	1
?	MM0581	CAPSCREW - M6 X 1.00 X 16	2
?	MM0459	FLAT WASHER - M6	2
?	MM0469	LOCKWASHER - M6	2
?	VD7127	MACHINE SCREW - #4 - 40NC X 1/2"	4
?	VN9762	FLAT WASHER - #4	4
?	VN9717	NUT - #4 - 40NC	4
?		NOTE: NS = NOT SHOWN
?	WA1578	TAPE, FILLER (1)
?	EB3432	SLEEVE, SHRINK (1)	12
?	PC0284	"Y" BOOT, SHRINK (1)	6
?	EG1834	SLEEVE, INSULATING
?	DC4979	CLAMP, WORM DRIVE	24
?		NOTE: (1) USE AT BUS BAR/CABLE CONNECTION.
