k-part

Item	PartNo	Description	Qty
?	58B-50-00760	HOUSING	1
?	WA0360	FLAT WASHER, HARDENED - 1/2"	1
?	VN9032	CAPSCREW - 1/2" - 13NC X 1"	1
?	58F-50-00370	PLUG	1
?	58B-50-00710	RETAINER, UPPER BEARING	1
?	WA0363	FLAT WASHER, HARDENED - 7/8"	60
?	VN9105	CAPSCREW - 7/8" - 9NC X 3"	36
?	58B-60-01240	BEARING, UPPER	1
?	58B-50-00920	LOCKPIN (1)	1
?	58B-50-00040	NUT, WHEEL	1
?	58B-50-00890	STOP, PISTON	1
?	SC3100	KEY, SQUARE	1
?	58B-50-40380	O-RING (1)	4
?	58B-50-40390	RING, BACKUP (1)	4
?	58B-50-00790	CAP, SUSPENSION	1
?	TY8879	PLUG, VENT (1)	1
?	VD5076	GASKET, FLAT (1)/(2)	1
?	PB2194	CHARGING VALVE ASSEMBLY (1)/(2)	1
?		(NOT USED IN THIS APPLICATION)
?	C1602	CAPSCREW - 3/8" - 16NC X 1"	2
?	DF3042	FLAT WASHER - 3/8"	2
?	TZ8637	PLUG, SENSOR	1
?	58B-60-01230	BEARING, LOWER	1
?	58B-50-50000	RETAINER, LOWER BEARING	1
?	58B-60-01220	SEAL, BUFFER (1)	1
?	58B-50-00180	SEAL, WIPER (1)	1
?	VN9161	CAPSCREW - 7/8" - 9NC X 4"	24
?	VN2710	CAPSCREW - 1" - 8NC X 5 1/2"	28
?	WA0364	FLAT WASHER, HARDENED - 1"	28
?	58B-50-40370	SEAL, MAIN (1)	1
?	58B-50-00800	PISTON ASSEMBLY	1
?	H2981	BALL, STEEL (1)	4
?	58B-50-00170	PLATE, WIPER RETAINER	4
?	WA0443	O-RING (1)	1
?	WA1443	RING, BACKUP (1)	1
?	EM3159	PLUG, PISTON	1
?	EM1585	RING, RETAINER	3
?	EM1600	PLATE, RETAINER	1
?	VM0314	PLUG (1)	1
?		NOTE: NS = NOT SHOWN
?	AK4063	SUSPENSION OIL MIXTURE - 5 GAL
?	AK4064	SUSPENSION OIL MIXTURE - 55 GAL
?	58B-FS-AK020	NOTE: (1) INCLUDED IN 58B-FS-AK020 SEAL KIT.
?	RK1887	(2) INCLUDED IN RK1887 CHARGING VALVE KIT.
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.)

Komatsu Parts Catalogs
