Корень Dump Trucks Komatsu AFE NEW AFE75-AE 980E-5 S/N A50102 - A50103, A50107 CERRO VERDE(afe75-ae)
SPINDLE, HUB AND BRAKE ASSEMBLY 1/3(834 : 62945)
Title Page Reference
SPINDLE, HUB AND BRAKE ASSEMBLY 2/3 836 63125





















































Item PartNo Description Qty Options Ref Alt
? 58B-32-00244 SPINDLE, HUB AND BRAKE ASSEMBLY 1
? 58B-32-00172 • HUB ASSEMBLY, WHEEL 1
? 58B-32-00103 • • HUB, WHEEL 1
? EK4352 • • STUD W/ HEAD 57
? WB1199 • PLUG, MAGNETIC 2
? TH6916 • VALVE, CHECK 1
? PB7454 • GAUGE, SIGHT 1
? VC6561 • CAPSCREW - 1/2" - 13NC X 1 1/2" 12
? TR5445 • LOCKWASHER - 1/2" 12
? 58B-32-00041 • COVER 1
? EK3776 • O-RING (1) 1
? VM8258 • CAPSCREW - 1" - 8NC X 3 3/4" 10
? TY2148 • FLAT WASHER, HARDENED - 1" 10
? 58B-32-00290 • RETAINER, BEARING 1
? EH7190 • O-RING (1) 1
? EK2731 • SHIM - .005" (1) 3
? EK2732 • SHIM - .007" (1) 4
? EK2733 • SHIM - .020" (1) 6
? PB9996 • CONE, ROLLER - TAPERED (1) 1
? PC0002 • CUP, ROLLER - TAPERED (1) 1
? EH7195 • O-RING (1) 2
? VN9037 • CAPSCREW - 3/8" - 16NC X 1 1/4" 12
? WA4726 • FLAT WASHER, HARDENED - 3/8" 12
? 58B-32-00060 • SHIM - .020" (1) 18
? 58B-32-00050 • SHIM - .010" (1) 12
? 58B-32-00192 • CARRIER, SEAL 1
? 58B-33-00011 • SEAL ASSEMBLY (1) 1
? 58B-33-11411 • • SEAL RING 2
? 58B-33-11420 • • O-RING 2
? PC1431 • SEAL, OIL (1) 1
? 58B-09-50080 • FLAT WASHER, HARDENED - 1 1/4" 35
? WB1231 • CAPSCREW - 1 1/4" - 12NF X 8" 32
? 58F-32-00180 • O-RING (1) 1
? DF6928 • CAPSCREW - 1/2" - 13NC X 1 3/4" 16
? 58B-32-00282 • CARRIER, SEAL - HUB 1
? 58B-32-40000 • SEAL ASSEMBLY (1) 1
? 58B-32-00261 • CARRIER, SEAL - SPINDLE 1
? EH7194 • O-RING (1) 1
? PC1131 • CUP, ROLLER - TAPERED (1) 1
? PC1130 • CONE, ROLLER - TAPERED (1) 1
? EK1288 • SPACER 1
? 58B-32-00620 • SPINDLE 1
? 562-22-32290 • PIN 2
? WA4174 • FLAT WASHER - 1" 54
? WA0908 • CAPSCREW - 1" - 8NC X 3" 54
? WB1134 NUT - 1 1/4" - 7NC (2) 3
? 58B-32-00370 BRACKET, SHIPPING (2) 3
? C1643 CAPSCREW - 3/4" - 10NC X 1 3/4" (2) 3
? WA0362 FLAT WASHER - 3/4" (2) 3
? 58B-SM-AK030 NOTE: (1) INCLUDED IN 58B-SM-AK030 SPINDLE MAINTENANCE KIT.
? (2) FOR SHIPPING AND STORAGE USE ONLY.
? (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.)
