Title	Page	Reference
AIR CLEANER 58F-02-00160	012	43406

Item	PartNo	Description	Qty	Ref
?	VC4898	CAPSCREW - 1/2" - 13NC X 2 1/2"	7
?	TL8151	JAM NUT - 1/2" - 20NF	14
?	PC1247	ROD END, FEMALE	14
?	EK1726	ROD, THREADED	1
?	DF3500	LOCKNUT - 1/2" - 13NC	13
?	WA4728	FLAT WASHER, HARDENED - 1/2"	27
?	WA0471	CAPSCREW - 1/2" - 13NC X 2 1/4"	6
?	EJ9909	CLAMP	7
?	WB1177	CLAMP, T-BOLT	12
?	VW7882	HOSE (TO OUTSIDE AIR CLEANER)	1
?	VC1390	LOCKWASHER - 5/8"	17
?	58F-09-00450	CAPSCREW - 5/8" - 11NC X 4 1/2"	13
?	WA4729	FLAT WASHER, HARDENED - 5/8"	13
?	58E-54-30540	BRACKET	1
?	MM0714	FLAT WASHER, HARDENED - M12	4
?	MM0616	CAPSCREW - M12 X 1.75 X 20	4
?	58F-02-00160	AIR CLEANER ASSEMBLY, DUAL (SEE INDEX)	1	43406
?	TX6040	ELBOW, RUBBER - 45 DEG	1
?	WB1179	CLAMP, T-BOLT	4
?	58E-54-30550	BRACKET	1
?	EJ9917	ROD, THREADED	1
?	TR9082	FLAT WASHER - 5/8"	4
?	TR2961	CAPSCREW - 5/8" - 11NC X 1"	4
?	TB1406	RAIN GUARD, FRONT	1
?	TB1019	RAIN GUARD, SIDE	1
?	58E-02-00600	TUBE, AIR INTAKE - LH OUTER FRONT	1
?	EK1727	ROD, THREADED	1
?	58E-54-30530	BRACKET	1
?	MM0604	CAPSCREW - M10 X 1.50 X 20	2
?	MM0713	FLAT WASHER, HARDENED - M10	2
?	VC8762	CAPSCREW - 3/8" - 16NC X 1 1/2"	3
?	HE5611	LOCKNUT - 3/8" - 16NC	3
?	WA4726	FLAT WASHER, HARDENED - 3/8"	6
?	EG7576	CLAMP, DOUBLE	2
?	TB1018	RAIN GUARD, SIDE	1
?	PC1115	HOSE, DOUBLE HUMP	2
?	EJ9910	ROD, THREADED	2
?	TV1918	CAPSCREW - 1/2" - 13NC X 1 3/4"	1
?	TR5445	LOCKWASHER - 1/2"	1
?	PC0858	ELBOW, REDUCING - 90 DEG	2
?	WB1169	CLAMP, T-BOLT	2
?	WB1170	CLAMP, T-BOLT	4
?	58E-02-00840	TUBE, AIR INTAKE - LH OUTER REAR	1
?	58E-02-00800	TUBE, AIR INTAKE - LH INNER FRONT	1
?	EK2341	ROD, THREADED	1
?	58E-02-00890	TUBE, AIR INTAKE - LH INNER REAR	1
?	EK1649	THREADED ROD	1

?
