Корень Dump Trucks Komatsu AFE NEW AFE59-FP 930E-4 S/N A31735 & A31750 - A31751 LOS PELAMBRES(afe59-fp)
CENTER DECK INSTALLATION(064 : 61528)







Item PartNo Description Qty Options Ref Alt
? XB4572 DECK, CENTER 1
? MM0075 CAPSCREW - M20 X 2.50 X 60 4
? MM0465 FLAT WASHER - M20 4
? MM0475 LOCKWASHER - M20 4
? MM0182 NUT - M20 X 2.50 4
? NOTE: NS = NOT SHOWN
? EM9049 SHIM 16
