Корень Excavators Komatsu PC138US-10 S/N F40003 AND UP(PC138U10)
TRACK SHOE ASSEMBLY (HOLED TRIPLE GROUSER SHOE, 500MM WIDTH, GREASE SEALED TYPE)(R0500-001001 : R0500-001001)





















Item PartNo Description Qty Options Ref Alt
? 203-32-03211 TRACK SHOE, ASSEMBLY 1
SN: F40003-
? 203-32-61120 • LINK, L.H. 42
SN: F40003-
? 203-32-61130 • LINK, R.H. 42
SN: F40003-
? 203-32-61360 • SEAL 80
SN: F40003-
? 203-32-61170 • BUSHING, MASTER 2
SN: F40003-
? 203-32-61140 • BUSHING 40
SN: F40003-
? 203-32-61151 • PIN 40
SN: F40003-
? 203-32-51461 • SHOE 42
SN: F40003-
? 22B-32-21230 • BOLT 168
SN: F40003-
? 203-32-61220 • NUT 168
SN: F40003-
? 203-32-61120 • LINK, L.H. 44
SN: F40003-
? 203-32-61130 • LINK, R.H. 44
SN: F40003-
? 203-32-61360 • SEAL 84
SN: F40003-
? 203-32-61170 • BUSHING, MASTER 2
SN: F40003-
? 203-32-61140 • BUSHING 42
SN: F40003-
? 203-32-61151 • PIN 42
SN: F40003-
? 203-32-51461 • SHOE 44
SN: F40003-
? 22B-32-21230 • BOLT 176
SN: F40003-
? 203-32-61220 • NUT 176
SN: F40003-
? 203-32-61380 • SEAL, MASTER 8
SN: F40003-
? 203-32-61191 • PIN, MASTER 4
SN: F40003-
