Корень Excavators Komatsu PC138US-10 S/N F40003 AND UP(PC138U10)
CAB, WITH 2-PIECE BOOM, DOOR ROLLER AND DOOR LOCK STRIKER(K1110-002045 : K1110-002045)























Item PartNo Description Qty Options Ref Alt
? 22B-54-01270 CAB, ASSEMBLY 1
SN: F40003-
? 22U-53-00111 • DOOR, ASSEMBLY 1
SN: F40003-
? 22B-54-27433 • • ROLLER, ASSEMBLY 1
SN: F40003-
? 22B-54-16490 • • PLATE 1
SN: F40003-
? 01435-41020 • • BOLT 2
SN: F40003-
? 22B-54-27591 • • ROLLER, ASSEMBLY 1
SN: F40003-
? 01010-D0820 • • BOLT 2
SN: F40003-
? 01643-70823 • • WASHER 2
SN: F40003-
? 22B-54-27452 • • ROLLER, ASSEMBLY 1
SN: F40003-
? 01010-D0820 • • BOLT 3
SN: F40003-
? 01643-70823 • • WASHER 3
SN: F40003-
? 22M-54-24880 • • STRIKER 2
SN: F40003-
? 20U-54-25341 • • SHIM, 1.100 MM 2
SN: F40003-
? 01435-40616 • • BOLT 4
SN: F40003-
? 22B-54-27491 • • BRACKET 1
SN: F40003-
? 22U-53-31540 • • BRACKET 1
SN: F40003-
? 01010-D1225 • • BOLT 6
SN: F40003-
? 01643-71232 • • WASHER 6
SN: F40003-
? 22M-54-24880 • • STRIKER 2
SN: F40003-
? 20U-54-25341 • • SHIM, 1.100 MM 2
SN: F40003-
? 01584-30605 • • NUT 4
SN: F40003-
? 01435-40616 • • BOLT 4
SN: F40003-
? 22B-54-27422 • • WEATHER STRIP 1
SN: F40003-
