Корень Excavators Komatsu PC138US-10 S/N F40003 AND UP(PC138U10)
CAB, WITH 2-PIECE BOOM, DOOR LOCK(K1110-002044 : K1110-002044)
































Item PartNo Description Qty Options Ref Alt
? 22B-54-01270 CAB, ASSEMBLY 1
SN: F40003-
? 22U-53-00111 • DOOR, ASSEMBLY 1
SN: F40003-
? 22B-54-16211 • • HANDLE 1
SN: F40003-
? 22B-54-16330 • • • SNAP 1
SN: F40003-
? 01023-10612 • • SCREW 2
SN: F40003-
? 22B-54-16220 • • HANDLE 1
SN: F40003-
? 22B-54-16330 • • • SNAP 1
SN: F40003-
? 22B-54-16370 • • • SPACER 1
SN: F40003-
? 01023-10612 • • SCREW 2
SN: F40003-
? 22B-54-16231 • • BRACKET 1
SN: F40003-
? 22B-54-16590 • • SEAL 1
SN: F40003-
? 01023-20616 • • SCREW 2
SN: F40003-
? 22B-54-16200 • • LINK, ASSEMBLY 1
SN: F40003-
? 01023-10612 • • SCREW 3
SN: F40003-
? 22B-54-27301 • • LINK, ASSEMBLY 1
SN: F40003-
? 01023-10612 • • SCREW 2
SN: F40003-
? 22B-54-27341 • • LOCK, ASSEMBLY 1
SN: F40003-
? 01240-00616 • • SCREW 3
SN: F40003-
? 195-Z11-1690 • • WASHER 3
SN: F40003-
? 22B-54-27351 • • LOCK, ASSEMBLY 1
SN: F40003-
? 01240-00616 • • SCREW 3
SN: F40003-
? 195-Z11-1690 • • WASHER 3
SN: F40003-
? 20Y-54-35890 • • LOCK, ASSEMBLY 1
SN: F40003-
? 205-54-71840 • • SNAP 1
SN: F40003-
? 22B-54-27361 • • COVER 1
SN: F40003-
? 22B-54-16461 • • RIVET 8
SN: F40003-
? 22B-54-27371 • • COVER 1
SN: F40003-
? 22B-54-16461 • • RIVET 4
SN: F40003-
? 22M-54-14470 • • HANDLE 1
SN: F40003-
? 21J-54-16630 • • GRIP 1
SN: F40003-
? 01252-70516 • • BOLT, HEXAGON SOCKET HEAD 2
SN: F40003-
? 01640-20508 • • WASHER 2
SN: F40003-
