Корень Excavators Komatsu PC138US-10 S/N F40003 AND UP(PC138U10)
CAB, WITH 2-PIECE BOOM, ROOF WINDOW(K1110-002042 : K1110-002042)























Item PartNo Description Qty Options Ref Alt
? 22B-54-01270 CAB, ASSEMBLY 1
SN: F40003-
? 22B-54-38531 • ROOF 1
SN: F40003-
? 2A5-53-11K11 • • HINGE 1
SN: F40003-
? 2A5-53-11K21 • • HINGE 1
SN: F40003-
? 01584-30806 • NUT 4
SN: F40003-
? 22B-54-28521 • COVER 1
SN: F40003-
? 09416-10200 • BUTTON 5
SN: F40003-
? 22B-54-38550 • PLATE 1
SN: F40003-
? 22B-54-28540 • SEAL 1
SN: F40003-
? 20Y-54-14590 • HANDLE 1
SN: F40003-
? 01245-00616 • SCREW 2
SN: F40003-
? 01643-70623 • WASHER 2
SN: F40003-
? 2A5-53-12940 • LOCK 1
SN: F40003-
? 20Y-53-11781 • KNOB 1
SN: F40003-
? 01435-40610 • BOLT 3
SN: F40003-
? 20Y-53-11931 • COVER 1
SN: F40003-
? 22B-54-38541 • GAS SPRING 2
SN: F40003-
? 2A5-53-12530 • PIN, SNAP 4
SN: F40003-
? 20Y-53-11771 • STRIKER 1
SN: F40003-
? 01245-00820 • SCREW 2
SN: F40003-
? 01643-70823 • WASHER 2
SN: F40003-
? 20Y-54-52651 • SPACER 2
SN: F40003-
? 22B-54-28550 • SEAL 1
SN: F40003-
