Корень Excavators Komatsu PC138US-10 S/N F40003 AND UP(PC138U10)
FLOOR FRAME, WITH 2-PIECE BOOM, FLOOR, PPC VALVE, RHS, INNER PARTS(K1110-002016 : K1110-002016)




















Item PartNo Description Qty Options Ref Alt
? 702-16-05190 PPC VALVE, ASSEMBLY 1
SN: F40003-
 X
? ☆ • HOLDER, VALVE W/CASE 1
SN: F40003-
? ☆ • PLUG 2
SN: F40003-
? ☆ • PLUG 2
SN: F40003-
? ☆ • VALVE 4
SN: F40003-
? 702-16-51140 • SHIM, 0.300 mm 4
SN: F40003-
 A
? 702-16-54670 • SHIM, 0.200 mm 4
SN: F40003-
 B
? 702-16-53420 • SPRING 4
SN: F40003-
? 702-16-53140 • RETAINER 4
SN: F40003-
? 702-16-51280 • SPRING 4
SN: F40003-
? 702-16-53170 • PISTON 4
SN: F40003-
? 702-16-71210 • WASHER 4
SN: F40003-
? 702-16-71160 • COLLAR 4
SN: F40003-
? 702-16-71280 • BOOT 1
SN: F40003-
? 702-16-71131 • PLATE 1
SN: F40003-
? 702-16-71141 • PLATE 1
SN: F40003-
? 01010-80620 • BOLT 4
SN: F40003-
? 702-16-51240 • JOINT 1
SN: F40003-
? 702-16-71361 • DISK 1
SN: F40003-
? 702-16-71441 • NUT 1
SN: F40003-
