Корень Excavators Komatsu PC138US-10 S/N F40003 AND UP(PC138U10)
MAIN PUMP (INNER PARTS) (5/9)(H0210-001005 : H0210-001005)



















Item PartNo Description Qty Options Ref Alt
? 708-3D-00040 PUMP, ASSEMBLY 1
SN: F40003-
 X
? (★ 708-3D-01040) • PUMP, SUBASSEMBLY 1
SN: F40003-
? (★ 708-3D-04330) • • BLOCK ASSEMBLY, FRONT 1
SN: F40003-
? ☆ • • • BLOCK, CYLINDER 1
SN: F40003-
? ☆ • • • PLATE, VALVE 1
SN: F40003-
? (★ 708-18-13230) • • PIN 1
SN: F40003-
? (★ 04065-04818) • • RING, SNAP 1
SN: F40003-
? (★ 708-2L-23131) • • SEAT 1
SN: F40003-
? (★ 708-2L-33160) • • SPRING 1
SN: F40003-
? (★ 708-7L-13140) • • SEAT 1
SN: F40003-
? (★ 708-2L-23351) • • SLEEVE 1
SN: F40003-
? (★ 708-2L-23360) • • PIN 3
SN: F40003-
? (★ 708-3D-13330) • • RETAINER, SHOE 1
SN: F40003-
? (★ 708-3D-13370) • • PISTON, SUBASSEMBLY 10
SN: F40003-
? (★ 708-3D-04430) • • CRADLE ASSEMBLY 1
SN: F40003-
? ☆ • • • CRADLE 1
SN: F40003-
? ☆ • • • CAM, ROCKER 1
SN: F40003-
? (★ 04020-01228) • • PIN, DOWEL 1
SN: F40003-
? (★ 01252-61230) • • BOLT, HEXAGON SOCKET HEAD 4
SN: F40003-

Excavators Komatsu / PC138US-10 S/N F40003 AND UP(PC138U10) / MAIN PUMP (INNER PARTS) (5/9)(H0210-001005 : H0210-001005)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
