Корень Excavators Komatsu PC100N-6 S/N 1004-UP(pc100n-r)
MAIN PUMP (2/6)(#1004-1190)(450230 : Y1600-02A0)




































Item PartNo Description Qty Options Ref Alt
? (708-1L-00043) PUMP ASS'Y 1
SN: 1004-1190
? THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 T0 Y1600-06A0.
? 708-1L-01032 • PUMP SUB ASS'Y 1
SN: 1004-1190
? (★708-2L-04011) • • CASE ASS'Y,FRONT 1
SN: 1004-1190
? ☆ • • • CASE,FRONT 1
SN: 1004-1190
? ☆ • • • PLUG 3
SN: 1004-1190
? 07044-12412 • • PLUG 1
SN: 1004-1190
? 07002-02434 • • O-RING 1
SN: 1004-1190
? 720-68-19870 • • PLUG 1
SN: 1004-1190
? 07002-01223 • • O-RING 1
SN: 1004-1190
? 04530-01018 • • BOLT,EYE 1
SN: 1004-1190
? 07043-01222 • • PLUG 2
SN: 1004-1190
? (★708-2L-24110) • • PISTON 1
SN: 1004-1190
? (★708-2L-24122) • • ROD 1
SN: 1004-1190
? (★708-2L-24161) • • STOPPER 1
SN: 1004-1190
? (★708-2L-24920) • • O-RING 1
SN: 1004-1190
? (★07001-03025) • • RING,BACK-UP 1
SN: 1004-1190
? (★708-2L-24220) • • BOLT 1
SN: 1004-1190
? (★708-2L-24151) • • SEAT 1
SN: 1004-1190
? (★708-2L-24230) • • WASHER 1
SN: 1004-1190
? (★708-2L-05010) • • SHIM KIT 1
SN: 1004-1190
? ☆ • • • SHIM 2
SN: 1004-1190
? ☆ • • • SHIM 2
SN: 1004-1190
? ☆ • • • SHIM 4
SN: 1004-1190
? (★708-2L-24312) • • SCREW 1
SN: 1004-1190
? (★07000-B2018) • • O-RING 1
SN: 1004-1190
? (★07001-02018) • • RING,BACK-UP 1
SN: 1004-1190
? (★01583-12716) • • NUT 1
SN: 1004-1190
? (★708-2L-25883) • • CAM 1
SN: 1004-1190
? (★01010-50620) • • BOLT 1
SN: 1004-1190
? (★01643-30623) • • WASHER 1
SN: 1004-1190
? (★04020-00514) • • PIN 2
SN: 1004-1190
? 708-2L-24141 • • SPRING 2
SN: 1004-1190
? 708-2L-24131 • • PLUG 2
SN: 1004-1190
? 07000-03030 • • O-RING 2
SN: 1004-1190
? (★708-2L-24340) • • SEAL,WASHER 1
SN: 1004-1190
