Корень Excavators Komatsu PC100N-6 S/N 1004-UP(pc100n-r)
SWIVEL JOINT (RELATED PARTS)(270070 : N1310-01A0)


















Item PartNo Description Qty Options Ref Alt
? (703-07-23100) SWIVEL JOINT ASS'Y,(SEE FIG.Y1627-01A0) 1
SN: 1004-
? 01010-81240 BOLT 4
SN: 1004-
? 01643-31232 WASHER 4
SN: 1004-
? 07230-20422 UNION 2
SN: 1004-
? 07002-12034 O-RING 2
SN: 1004-
? 07230-20210 UNION 1
SN: 1004-
? 07002-01423 O-RING 1
SN: 1004-
? 203-62-56710 ELBOW 1
SN: 1004-
? 07002-02034 O-RING 1
SN: 1004-
? 07238-10315 CONNECTOR 1
SN: 1004-
? 07230-20422 UNION 2
SN: 1004-
? 07002-12034 O-RING 2
SN: 1004-
? 20X-60-41110 LINK 1
SN: 1004-
? 201-60-11230 PIN 1
SN: 1004-
? 04050-14030 PIN,COTTER 1
SN: 1004-
? 01641-21626 WASHER 1
SN: 1004-
? 04050-14030 PIN,COTTER 1
SN: 1004-
? 01641-21626 WASHER 1
SN: 1004-
