Корень Excavators Komatsu PC100N-6 S/N 1004-UP(pc100n-r)
FLOOR (FLOOR FRAME)(#1004-1190)(210400 : K1110-01A0)










Item PartNo Description Qty Options Ref Alt
? 203-54-64360 FLOOR FRAME 1
SN: 1004-1190
? 201-54-73211 BRACKET 1
SN: 1004-1190
? 01010-81025 BOLT 4
SN: 1004-1190
? 01643-31032 WASHER 4
SN: 1004-1190
? 201-54-73142 COVER 1
SN: 1004-1190
? 01010-81020 BOLT 2
SN: 1004-1190
? 01643-31032 WASHER 2
SN: 1004-1190
? 07049-01012 PLUG 2
SN: 1004-1190
? 09452-06506 CATCHER 2
SN: 1004-1190
? 01224-40408 SCREW 4
SN: 1004-1190
