Item	PartNo	Description	Qty
?	VM5106	• PAD, RUBBER BODY	2
?	C1602	• • CAPSCREW - 3/8" - 16NC X 1"	8
?	C0312	• • LOCKWASHER - 3/8"	8
?	EC7717	• • HOUSING, AXLE	1
?	TZ2811	• • EYE, PIVOT (1)	1
?	TK5081	• • PIN (2)	1
?	TK5080	• • SPACER (2)	1
?	WA0364	• • LOCKWASHER - 1"	2
?	VM8258	• • CAPSCREW - 1" - 8NC X 3 3/4"	2
?	C1632	• • CAPSCREW - 5/8" - 11NC X 2 1/2"	3
?	C1541	• • LOCKWASHER - 5/8"	3
?	EC8134	• • CAPSCREW - HEAD DRILLED	4
?	TY9757	• • RETAINER, PLATE	1
?	TZ2813	• • SPACER	2
?	PB0027	• • BUSHING, BALL (1)	1
?	TZ2810	• • RETAINER, BEARING	1
?	TZ2812	• • PIN, PIVOT	1
?	VN9179	• • CAPSCREW - 3/4" - 10NC X 6"	8
?	VL2993	• • LOCKNUT - 3/4" - 10NC	8
?	PB7373	• • COVER, RING	1
?	TG1874	• • CLAMP	2
?	PB7372	• • COVER, RING	1
?	C1644	• • CAPSCREW - 3/4" - 10NC X 2"	3
?	VN9106	• • CAPSCREW - 1 1/4" - 7NC X 3"	18
?	VL4462	• • WIRE, GROUND	1
?	VH9969	• • WELD STUD - 3/8" - 16NC X 3/4"	2
?	C1521	• • NUT - 3/8" - 16NC	2
?	TX6695	• • SPACER, BEARING	1
?	TX6694	• • RETAINER, PLATE	1
?	FB6313	• • ANTI-SWAY BAR ASSM	1
?	VL8581	• • BAR, ANTI-SWAY	1
?	VN9350	• • SNAP RING (2)	2
?	VL4293	• • BEARING (2)	2
?	TK5082	• • PLATE, LOCKING	1
?	TZ3346	• • PLATE, LOCKING	1
?	VH0596	• • ELBOW - 90 DEG	2
?	C1231	• • COUPLING, PIPE	2
?	CD3705	• • NIPPLE	1
?	HA9432	• • HOSE	1
?	A1377	• • BAR, LOCK	1
?	VC2195	• • WELD STUD - 3/8" - 16NC X 1"	1
?	TG2568	• • CLAMP	1
?	HA9426	• • HOSE	1
?		• • NOTE: (1) INCLUDED IN TZ2991 PIVOT EYE ASSM.	65535
?	AK0971	• • (2) INCLUDED IN AK0971 - PIN KIT (ANTI-SWAY BAR)	65535
