Item |
PartNo |
Description |
Qty |
Options |
Ref |
Alt |
|
? |
TZ9709 |
• FRONT SUSPENSION ASSM - 13" |
1 |
|
|
|
|
? |
WA2892 |
• • PLATE, WARNING |
2 |
|
|
|
|
? |
R1073 |
• • DRIVE SCREW - #6 X 3/16" |
8 |
|
|
|
|
? |
VN9087 |
• • CAPSCREW - 5/8" - 11NC X 2 1/2" |
24 |
|
|
|
|
? |
WA0361 |
• • FLAT WASHER - 5/8" |
48 |
|
|
|
|
? |
TZ9701 |
• • CAP, SUSPENSION |
1 |
|
|
|
|
? |
TY8879 |
• • PLUG, VENT |
1 |
|
|
|
|
? |
TM9278 |
• • PROTECTOR |
1 |
|
|
|
|
? |
C1602 |
• • CAPSCREW - 3/8" - 16NC X 1" |
2 |
|
|
|
|
? |
C0312 |
• • LOCKWASHER - 3/8" |
2 |
|
|
|
|
? |
PB2194 |
• • CHARGING VALVE ASSM (1)(2) |
1 |
|
|
|
|
? |
TD7179 |
• • CORE |
1 |
|
|
|
|
? |
TR9993 |
• • CAP |
1 |
|
|
|
|
? |
TF1144 |
• • O-RING |
1 |
|
|
|
|
? |
WA0052 |
• • O-RING |
1 |
|
|
|
|
? |
VD5076 |
• • GASKET (1)(2) |
1 |
|
|
|
|
? |
WA0105 |
• • SEAL, O-RING (2) |
4 |
|
|
|
|
? |
WA1280 |
• • RING, BACKUP (2) |
4 |
|
|
|
|
? |
VN9105 |
• • CAPSCREW - 7/8" - 9NC X 3" |
12 |
|
|
|
|
? |
WA0363 |
• • FLAT WASHER - 7/8" |
12 |
|
|
|
|
? |
TZ7658 |
• • BEARING, BRONZE (UPPER) |
1 |
|
|
|
|
? |
TY8125 |
• • WASHER, SNUBBER |
1 |
|
|
|
|
? |
H2981 |
• • BALL, STEEL - 3/4" |
2 |
|
|
|
|
? |
VW4451 |
• • NUT, WHEEL |
1 |
|
|
|
|
? |
VC2629 |
• • PIN |
1 |
|
|
|
|
? |
EF7977 |
• • PISTON |
1 |
|
|
|
|
? |
TZ7653 |
• • BEARING, BRONZE (LOWER) |
1 |
|
|
|
|
? |
VN9129 |
• • CAPSCREW - 5/8" - 11NC X 3 3/4" |
24 |
|
|
|
|
? |
VM0314 |
• • PLUG, O-RING |
1 |
|
|
|
|
? |
VJ3911 |
• • OIL, SUSPENSION - STANDARD (5 GALLON CAN) |
4 |
|
|
|
|
? |
TZ9718 |
• • HOUSING |
1 |
|
|
|
|
? |
PB7977 |
• • SEAL, ROD BUFFER - 13" (2) |
1 |
|
|
|
|
? |
PB8565 |
• • SEAL, ROD DOUBLE LIP - 13" (2) |
1 |
|
|
|
|
? |
WA4880 |
• • SEAL, WIPER - 13" (2) |
1 |
|
|
|
|
? |
TZ1626 |
• • PLATE |
1 |
|
|
|
|
? |
TZ8637 |
• • PLUG, SENSOR |
1 |
|
|
|
|
? |
WA0404 |
• • NUT - 1 1/2" - 6NC |
10 |
|
|
|
|
? |
TZ1637 |
• • KEY, SHEAR |
1 |
|
|
|
|
? |
EB2080 |
• • CAPSCREW - 1/2" - 13NC X 10 3/4" |
8 |
|
|
|
|
? |
TX9710 |
• • SPACER |
4 |
|
|
|
|
? |
TZ4354 |
• • BOOT |
1 |
|
|
|
|
? |
TZ4355 |
• • WIRE, BOOT |
1 |
|
|
|
|
? |
WA1754 |
• • CLAMP, HOSE |
2 |
|
|
|
|
? |
VN9182 |
• • CAPSCREW - 1/2" - 13NC X 6" |
6 |
|
|
|
|
? |
WA0368 |
• • FLAT WASHER - 1 1/2" |
24 |
|
|
|
|
? |
TY2149 |
• • FLAT WASHER |
8 |
|
|
|
|
? |
TZ1439 |
• • PLATE, RETAINER (SEE FIG 30682) |
1 |
|
|
|
|
? |
WA4817 |
• • CAPSCREW - 1 1/4" - 12NF X 5" (12 POINT) |
8 |
|
|
|
|
? |
RK1887 |
• • NOTE: (1) USED IN RK1887 REAPAIR KIT. |
65535 |
|
|
|
|
? |
AK7159 |
• • (2) USED IN AK7159 SEAL KIT. |
65535 |
|
|
|
|
? |
|
• • (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY) |
65535 |
|
|
|
