Item	PartNo	Description	Qty
?	1268363H1	• SCREW	4
?	1285725H1	• • PLATE	1
?	VE8216	• • PLUG, BEARING WELL (1)	1
?	VE8209	• • SCREW	2
?	VE8210	• • WASHER, PLAIN	1
?	VE8206	• • NUT & WASHER	3
?	1285727H1	• • DIODE	1
?	1268364H1	• • SCREW & LOCKWASHER	2
?	VE8202	• • BRIDGE, RECTIFIER	1
?	VE8208	• • SCREW	1
?	1268267H1	• • SCREW & WASHER	2
?	1285729H1	• • CONNECTOR	1
?	VE8206	• • NUT & WASHER	1
?	1218115H1	• • REGULATOR	1
?	1213274H1	• • CAP	1
?	1285728H1	• • CONNECTOR	1
?	1213256H1	• • TERMINAL, RELAY PACKAGE	1
?	VE8205	• • LOCKWASHER, GROUND	1
?	VE8204	• • SCREW, GROUND TERMINAL	1
?	1285730H1	• • TERMINAL, OUTPUT PACKAGE	1
?	1268364H1	• • SCREW & LOCKWASHER	1
?	VE8203	• • CAPACITOR	1
?	1213242H1	• • BUSHING (1)	1
?	VE0204	• • BEARING (1)	1
?	VE0206	• • BEARING	1
?	1285726H1	• • HOUSING	1
?	VE8213	• • CUP - STATOR LEADS (2)	1
?	VE8215	• • GROMMET (2)	1
?	1285732H1	• • STATOR	1
?	1285734H1	• • COIL	1
?	1213254H1	• • ROTOR	1
?	1285736H1	• • RETAINER W/SEAL	1
?	1285737H1	• • COLLAR	1
?	1213268H1	• • BEARING	1
?	VE8201	• • HOUSING, DRIVE END	1
?	VE8212	• • THRU BOLT	4
?	1285739H1	• • SCREW	1
?	1285738H1	• • FAN, ALTERNATOR	1
?		• • PULLEY, DRIVE (3)	1
?	VE8211	• • WASHER, SHAFT NUT	1
?	VE8207	• • NUT, SHAFT	1
?		• • NOTE: (1) INCLUDED IN ITEM 28, 1285726H1 HOUSING	65535
?		• • (2) INCLUDED IN ITEM 31, 1285732H1 STATOR.	65535
?		• • (3) SERVICED BY ENGINE MANUFACTURER.	1
