Корень Dump Trucks Komatsu AFE42-Q 630E S/N 32418 LEIGHTON(afe42-q)
L.H. DECK WIRING INSTL(382 : 35312)





























Item PartNo Description Qty Options Ref Alt
? WA0193 • WELD STUD - 1/4" - 20NC X 1" 1
? R6262 • • LOCKWASHER - 1/4" (EXTERNAL TOOTH) 1
? TD1549 • • NUT - 1/4" - 20NC 1
? TF1207 • • BUZZER - 24V 2
? H8136 • • CAPSCREW - 1/4" - 20NC X 1/2" 4
? C5774 • • LOCKWASHER - 1/4" 4
? TK0253 • • VARISTOR 2
? TX3086 • • HOUSING 1
? TX3363 • • HOUSING 1
? SF9896 • • DISCONNECT, KNIFE 2
? VL9602 • • CLAMP 2
? C1601 • • CAPSCREW - 3/8" - 16NC X 3/4" 2
? C0312 • • LOCKWASHER - 3/8" 2
? C1521 • • NUT - 3/8" - 16NC 2
? DF3042 • • FLAT WASHER - 3/8" 2
? SG3146 • • GROMMET 2
? EC9261 • • HARNESS, BRAKE VALVE 1
? WA3367 • • NUT ASSM 80
? VS8193 • • BOARD TERMINAL - 20 POINT 4
? VS5317 • • MACHINE SCREW - #10 3
? DC3101 • • LOCKWASHER - #10 6
? VM1464 • • MACHINE SCREW - #10 - 24NC X 5/8" 1
? EC7687 • • BRACKET 1
? • • (NOT USED THIS APPLICATION) 65535
? VC9144 • • MACHINE SCREW - #8 - 32NC X 1/2" 4
? SG3408 • • NUT - #10 - 24NC 1
? TX6953 • • BRACKET 1
? HC9043 • • DISCONNECT, KNIFE 1
? DF0017 • • NUT - #10 - 24NC 1
