Корень Dump Trucks Komatsu AFE42-Q 630E S/N 32418 LEIGHTON(afe42-q)
FUEL TANK PIPING(360 : 35404)















Item PartNo Description Qty Options Ref Alt
? TD9741 • FITTING, TUBE 1
? HA6116 • • HOSE 1
? WA2534 • • WELD STUD - 1/2" - 13NC X 1 5/8" 1
? C1540 • • LOCKWASHER - 1/2" 5
? C1523 • • NUT - 1/2" - 13NC 5
? VL9602 • • CLAMP 1
? WB0367 • • FITTING, STRAIGHT 1
? VN9999 • • CLAMP 4
? EB8864 • • TUBE 1
? TF6990 • • FITTING, TUBE 1
? HA4161 • • HOSE 1
? WB0300 • • FITTING - 45 DEG 1
? WB0297 • • FITTING - 45 DEG 1
? WB0275 • • FITTING - 90 DEG 1
? WB0270 • • FITTING - 90 DEG 1
