Корень Dump Trucks Komatsu AFE42-Q 630E S/N 32418 LEIGHTON(afe42-q)
CONTROL CABINET WIRING - 2(288 : 30733)











Item PartNo Description Qty Options Ref Alt
? ED6893 • HARNESS, RB4 1
? ED6900 • • HARNESS, DB1 1
? ED6894 • • HARNESS, DB1 1
? ED6899 • • HARNESS, DB1 1
? ED6895 • • HARNESS, RB2 1
? ED8152 • • HARNESS - RB3 (1) 1
? ED8151 • • HARNESS - RB1 (1) 1
? ED8154 • • HARNESS - RB3 (1) 1
? ED8155 • • HARNESS - RB5 (1) 1
? • • NOTE: (1) THESE HARNESS ORIGINATE IN THE JUNCTION BOX 65535
? • • ASSM (SEE FIG. 35421). 65535
