Корень Dump Trucks Komatsu AFE42-Q 630E S/N 32418 LEIGHTON(afe42-q)
ARC BARRIER ASSM (EC7343)(262 : 40558)


















Item PartNo Description Qty Options Ref Alt
? ED3409 • BRACKET 6
? MM0469 • • LOCKWASHER - M6 34
? MM0176 • • NUT - M6 34
? MM0459 • • FLAT WASHER - M6 52
? EC7328 • • ARC BARRIER 1
? EC7081 • • BRACKET, ARC BARRIER 1
? EC7077 • • BRACKET, ARC BARRIER 1
? EC7083 • • SHELF, ARC BARRIER 1
? EC2012 • • BRACKET, INSULATED 6
? EC7078 • • SHELF, ARC BARRIER 1
? MM0027 • • CAPSCREW - M6 X 1 X 25 18
? EC2003 • • ARC BARRIER 1
? EC2017 • • STUD, THREADED 1
? EB9024 • • BRACKET, MOUNTING 2
? EC2016 • • SPACER, TUBE 1
? EC2018 • • SPACER, TUBE 1
? EC0465 • • ARC BARRIER 1
? EC2019 • • STUD, THREADED 1
