Item |
PartNo |
Description |
Qty |
Options |
Ref |
Alt |
|
? |
PB9266 |
• ALTERNATOR, BLOWER & EXCITER ASSM |
1 |
|
|
|
|
? |
PB8785 |
• • WHEEL, MOTORIZED (788HS8) |
2 |
|
|
|
|
? |
LW18527 |
• • OIL, LUBE (5 GAL CONTAINER) |
2 |
|
|
|
|
? |
VN3270 |
• • CAPSCREW - 1 1/4" - 7NC X 5" |
96 |
|
|
|
|
? |
WA0366 |
• • FLAT WASHER - 1 1/4" (HARDENED) |
96 |
|
|
|
|
? |
TK5255 |
• • BAR, BUS |
2 |
|
|
|
|
? |
PB6489 |
• • RECTIFIER, PANEL |
1 |
|
|
|
|
? |
|
• • CABINET, CONTROL (SEE INDEX) |
1 |
|
|
|
|
? |
CH2549 |
• • CABLE - 74AF (DRIVE WHEEL TO DRIVE WHEEL) |
1 |
|
|
|
|
? |
CH2542 |
• • CABLE - 7J4 (MF CONTACTOR TO LEFT WHEEL MOTOR) |
1 |
|
|
|
|
? |
CH2543 |
• • CABLE - 7J9 (S3 SHUNT TO RIGHT WHEEL MOTOR) |
1 |
|
|
|
|
? |
ED3914 |
• • CABLE |
1 |
|
|
|
|
? |
CH2640 |
• • CABLE - 7J2 (P1 CONTACTOR TO LEFT WHEEL MOTOR) |
1 |
|
|
|
|
? |
CH2641 |
• • CABLE - 7JIR (CONTROL CABINET TO RIGHT WHEEL MOTOR) |
1 |
|
|
|
|
? |
CH2643 |
• • CABLE - 7GA1 (CONTROL CABINET FROM LEFT WHEEL MOTOR) |
1 |
|
|
|
|
? |
CH2642 |
• • CABLE - 7J1L (CONTROL CABINET TO LEFT WHEEL MOTOR) |
1 |
|
|
|
|
? |
CH2546 |
• • CABLE - 74 (ALTERNATOR TO GF CONTACTOR) |
1 |
|
|
|
|
? |
CH2525 |
• • CABLE - 74AA (ALTERNATOR TO AFSE CONTACTOR) |
1 |
|
|
|
|
? |
CH3120 |
• • CABLE - T1 (ALTERNATOR TO RECTIFIER) |
1 |
|
|
|
|
? |
CH3121 |
• • CABLE - T2 (ALTERNATOR TO RECTIFIER) |
1 |
|
|
|
|
? |
CH3122 |
• • CABLE - T3 (ALTERNATOR TO RECTIFIER) |
1 |
|
|
|
|
? |
CH2545 |
• • CABLE - 75X (ALTERNATOR - T15 TO MFSE PANEL) |
1 |
|
|
|
|
? |
CH2544 |
• • CABLE - 74D (ALTERNATOR - T14 TO S6 SHUNT) |
1 |
|
|
|
|
? |
CH2521 |
• • CABLE - 71J (ALTERNATOR - T13 TO AFSE PANEL) |
1 |
|
|
|
|
? |
CH2541 |
• • CABLE - 71G (ALTERNATOR - T16 TO S7 SHUNT) |
1 |
|
|
|
|
? |
EC9108 |
• • HARNESS - (GRR PANEL TO GF1P AND VMM2) |
1 |
|
|
|
|
? |
TY8242 |
• • CABLE - (RECTIFIER TO FILTER PANEL) |
1 |
|
|
|
|
? |
CH2636 |
• • CABLE - 7J10 (CONTROL CABINET TO BLOWN GRID) |
1 |
|
|
|
|
? |
CH2639 |
• • CABLE - 7J2 (P1 CONTACTOR TO BLOWN GRID) |
1 |
|
|
|
|
? |
CH2679 |
• • CABLE - 7J8 (RP1 CONTACTOR TO BLOWN GRID) |
1 |
|
|
|
|
? |
CH2678 |
• • CABLE - 7J7 (RP2 CONTACTOR TO BLOWN GRID) |
1 |
|
|
|
|
? |
EC9112 |
• • HARNESS |
1 |
|
|
|
|
? |
CH2157 |
• • CABLE 7J1 (RP2 CONTACTOR TO LOAD TEST BOX) |
1 |
|
|
|
|
? |
CH2158 |
• • CABLE - 7J7 (RP2 CONTACTOR TO LOAD TEST BOX) |
1 |
|
|
|
|
? |
CH2159 |
• • CABLE - 7J8 (RP1 CONTACTOR TO LOAD TEST BOX) |
1 |
|
|
|
|
? |
CH2156 |
• • CABLE - 7J1LS (SHUNT BOX TO LOAD TEST BOX) |
1 |
|
|
|
|
? |
CH2155 |
• • CABLE - 7J1RS (SHUNT BOX TO LOAD TEST BOX) |
1 |
|
|
|
|
? |
CH3123 |
• • CABLE - 7GA1 (RECTIFIER TO CONTOL CABINET) |
1 |
|
|
|
|
? |
CH2160 |
• • CABLE - 7GA2 (RECTIFIER TO P1 CABINET) |
1 |
|
|
|
|
? |
EB2399 |
• • HARNESS - (CONTROL CABINET TO BLOWN GRID) |
1 |
|
|
|
|
? |
EC7269 |
• • CABLE - (SHUNT BOX TO ISOA3 AND 4) |
1 |
|
|
|
|
? |
YA3179 |
• • HARNESS - TO ALTERNATOR (ESS) ENGINE CONTROL |
1 |
|
|
|
|
? |
|
• • CABLE, MAGNETIC PICKUP (FURISHED W/ALTERNATOR) |
1 |
|
|
|
