Корень Excavators Komatsu PC240NLC-8K S/N K50001-UP(pc240n2u)
MAIN VALVE (FOR 2-PIECE BOOM) (1 ACTUATOR) (4/21)(017078 : Y1664-34A0)





















Item PartNo Description Qty Options Ref Alt
? (723-48-23802) VALVE ASSEMBLY 1
SN: K50741-
? (723-48-23800) VALVE ASSEMBLY 1
SN: K50001-K50740
? THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1664-31A0 T0 Y1664-51A0.
? ☆ • BODY SUB ASSEMBLY 1
SN: K50001-
? 723-46-15111 • • CASE 2
SN: K50001-
? 723-46-18500 • • CASE SUB ASSEMBLY 1
SN: K50001-
? ☆ • • • CASE 1
SN: K50001-
? ☆ • • • PISTON 1
SN: K50001-
? ☆ • • • SEAL 1
SN: K50001-
? 723-46-15630 • • • PLUG 1
SN: K50001-
? 07000-13024 • • • O-RING 1
SN: K50001-
? 723-46-18600 • • CASE SUB ASSEMBLY 1
SN: K50001-
? ☆ • • • CASE 1
SN: K50001-
? ☆ • • • PISTON 1
SN: K50001-
? ☆ • • • SEAL 1
SN: K50001-
? 723-46-15630 • • • PLUG 1
SN: K50001-
? 07000-13024 • • • O-RING 1
SN: K50001-
? 07430-71380 • • O-RING 12
SN: K50001-
? 702-16-53920 • • O-RING 10
SN: K50001-
? 01252-60820 • • BOLT 22
SN: K50001-
? 723-46-17350 • • BOLT 2
SN: K50001-
