Корень Excavators Komatsu PC240NLC-8K S/N K50001-UP(pc240n2u)
MAIN VALVE (2-ACTUATOR) (20/21)(017073 : Y1664-20A0)










Item PartNo Description Qty Options Ref Alt
? (723-48-24202) VALVE ASSEMBLY 1
SN: K50679-
? (723-48-24200) VALVE ASSEMBLY 1
SN: K50001-K50678
? THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1664-01A0 T0 Y1664-21A0.
? ☆ • BODY SUB ASSEMBLY 1
SN: K50001-
? 723-46-40500 • • VALVE ASSEMBLY 2
SN: K50001-
? 700-93-11320 • • • O-RING 1
SN: K50001-
? 723-46-41950 • • • RING 2
SN: K50001-
? 07002-13634 • • • O-RING 1
SN: K50001-
? 01252-60845 • • BOLT 4
SN: K50001-
? 01643-50823 • • WASHER 4
SN: K50001-
