Корень Excavators Komatsu PC240NLC-8K S/N K50001-UP(pc240n2u)
TRAVEL MOTOR (1/3)(017032 : Y1641-01A0)




































Item PartNo Description Qty Options Ref Alt
? 708-8F-00192 MOTOR ASSEMBLY 1
SN: K50001-
? THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1641-01A0 TO Y1641-03A0.
? (★708-8F-04660) • CASE SUB ASSEMBLY 1
SN: K50001-
? ☆ • • CASE, MOTOR 1
SN: K50001-
? ☆ • • PLUG 1
SN: K50001-
? (★708-8F-04192) • END COVER SUB ASSEMBLY 1
SN: K50001-
? ☆ • • COVER, END 1
SN: K50001-
? ☆ • • SPOOL 1
SN: K50001-
? ☆ • • PLUG 3
SN: K50001-
? ☆ • • PLUG 2
SN: K50001-
? ☆ • • SPOOL 1
SN: K50001-
? (★708-8F-34220) • • SPRING 1
SN: K50001-
? 708-8H-11530 • PLUG 3
SN: K50001-
? 07002-11423 • O-RING 3
SN: K50001-
? 20B-27-11210 • BLEEDER 1
SN: K50001-
? 708-8F-36611 • SPRING 2
SN: K50001-
? ☆ • RING 2
SN: K50001-
? 708-8H-36121 • SPRING 2
SN: K50001-
? 708-8F-36311 • COVER 2
SN: K50001-
? 07000-13040 • O-RING 2
SN: K50001-
? 700-93-11320 • O-RING 2
SN: K50001-
? 07000-11009 • O-RING 2
SN: K50001-
? 01252-61235 • BOLT 12
SN: K50001-
? 708-8F-34120 • VALVE 2
SN: K50001-
? 722-10-91130 • SPRING 2
SN: K50001-
? 708-8F-34110 • PLUG 2
SN: K50001-
? 07002-11823 • O-RING 2
SN: K50001-
? 708-8E-16180 • VALVE 1
SN: K50001-
? 708-8F-31660 • PLUG 1
SN: K50001-
? 07000-11006 • O-RING 1
SN: K50001-
? 07001-01006 • RING 1
SN: K50001-
? 07002-11223 • O-RING 1
SN: K50001-
? 708-8F-31610 • O-RING 1
SN: K50001-
? 07000-11009 • O-RING 1
SN: K50001-
? (★04020-01228) • PIN 1
SN: K50001-
? 708-8F-31210 • BOLT 4
SN: K50001-
