Корень Wheel Loaders Komatsu WA350-3-H S/N 63001-UP(wa350-7r)
LOADER CONTROL (WORK EQUIPMENT LOCK LEVER) (WITH ADDITIONAL 2-SPOOL CONTROL VALVE)(241500 : K4500-03A3)













Item PartNo Description Qty Options Ref Alt
? 421-43-28220 SHAFT 1
SN: 63001-
? 04025-00520 PIN,SPRING 1
SN: 63001-
? 203-43-21370 SPRING 1
SN: 63001-
? 01435-01220 BOLT 2
SN: 63001-
? 421-43-28450 LEVER 1
SN: 63001-
? 04025-00520 PIN,SPRING 1
SN: 63001-
? 09305-00800 KNOB 1
SN: 63001-
? 421-43-28520 LEVER 1
SN: 63001-
? 421-V91-2510 BRACKET ASS'Y 1
SN: 63001-
? 421-09-21220 • BUSHING 2
SN: 63001-
? 421-V91-2480 LEVER ASS'Y 1
SN: 63001-
? 421-09-21220 • BUSHING 2
SN: 63001-
? 417-43-18410 SHIM¤ 0.8MM 2
SN: 63001-
