Корень Excavators Komatsu PW220-7H S/N H50051-UP(pw220_7h)
FRONT AXLE (2/5) (2.75M WIDTH) STEERING ARM(S0-30 : S1150-52A1)













Item PartNo Description Qty Options Ref Alt
? (20K-23-32001) AXLE ASSEMBLY 1
SN: H50051-
? (THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS. P1450-51A1 TO P1450-56A1)
? 20K-23-31260 • TIE ROD ASSEMBLY 2
SN: H50051-
? 20K-23-31270 • • TIE ROD 1
SN: H50051-
? 20K-23-31280 • • BEARING 2
SN: H50051-
? 20K-23-31290 • • NIPPLE 2
SN: H50051-
? 20K-23-31310 • • CAP, PROTECTION 2
SN: H50051-
? 20K-23-31350 • FORK 2
SN: H50051-
? 20K-23-31360 • PIN 4
SN: H50051-
? 20K-23-31440 • SCREW 2
SN: H50051-
? 20K-23-31450 • PIN 4
SN: H50051-
? 20K-23-31460 • WASHER 16
SN: H50051-
? 20K-23-31470 • WASHER 6
SN: H50051-
