Корень Excavators Komatsu PC180NLC-7-E0 S/N K45001-UP(pc180n2u)
BURST VALVE LINE (BOOM CYLINDER SIDE)(150140 : H1250-01H0)
























Item PartNo Description Qty Options Ref Alt
? (702-21-08330) PILOT VALVE,(SEE FIG.Y1679-11A0) 1
SN: K45001-
? 07372-21050 BOLT 2
SN: K45001-
? 01643-51032 WASHER 2
SN: K45001-
? 07372-21060 BOLT 2
SN: K45001-
? 01643-51032 WASHER 2
SN: K45001-
? 07000-13030 O-RING 1
SN: K45001-
? (702-21-08350) PILOT VALVE,(SEE FIG.Y1679-11A1) 1
SN: K45001-
? 07372-21050 BOLT 2
SN: K45001-
? 01643-51032 WASHER 2
SN: K45001-
? 07372-21060 BOLT 2
SN: K45001-
? 01643-51032 WASHER 2
SN: K45001-
? 07000-13030 O-RING 1
SN: K45001-
? 21K-62-74310 TUBE 1
SN: K45001-
? 07000-13030 O-RING 1
SN: K45001-
? 07372-21035 BOLT 4
SN: K45001-
? 01643-51032 WASHER 4
SN: K45001-
? 21K-62-74320 TUBE 1
SN: K45001-
? 07000-13030 O-RING 1
SN: K45001-
? 07372-21035 BOLT 4
SN: K45001-
? 01643-51032 WASHER 4
SN: K45001-
? 07283-32738 CLIP 2
SN: K45001-
? 01597-01009 NUT 4
SN: K45001-
? 01643-31032 WASHER 4
SN: K45001-
? 02896-61018 O-RING 2
SN: K45001-
