Корень Excavators Komatsu PC228US-2 S/N 15001-UP(pc228u4r)
COOLING (SUB TANK AND RADIATOR MOUNT)(060040 : C0100-02A0)




















Item PartNo Description Qty Options Ref Alt
? 203-03-61640 TANK 1
SN: 15001-
? 205-03-71532 • CAP 1
SN: 15001-
? 205-03-71540 • • PACKING 1
SN: 15001-
? 208-03-58290 HOSE 1
SN: 15001-
? 206-03-43340 CLIP 1
SN: 15001-
? 22U-03-11241 BRACKET 1
SN: 15001-
? 203-03-56650 BRACKET 1
SN: 15001-
? 01010-80820 BOLT 2
SN: 15001-
? 01643-30823 WASHER 2
SN: 15001-
? 08034-00536 BAND 1
SN: 15001-
? 22U-03-11250 HOSE 1
SN: 15001-
? 206-03-43340 CLIP 2
SN: 15001-
? 01010-81225 BOLT 2
SN: 15001-
? 01643-31232 WASHER 2
SN: 15001-
? 22U-03-11230 STAY 2
SN: 15001-
? 01010-81635 BOLT 4
SN: 15001-
? 01643-31645 WASHER 2
SN: 15001-
? 21T-54-16150 WASHER 2
SN: 15001-
? 01010-81650 BOLT 4
SN: 15001-
? 01643-31645 WASHER 4
SN: 15001-
